GlobalFIX V4 406 MHZ GPS EPIRB - CLASS 2 - CAT 1

The all-new GlobalFIX V4 406 MHZ GPS EPIRB - CLASS 2 - CAT 1 is specifically designed to meet Australian and New Zealand standards. This is the Category I - Hydrostatic release (auto) model

  • Product Code: BEGF2830
  • Brand: ACR


Drastically increase your probability of survival at sea with the multiple built-in redundancies of the GlobalFIX™ V4 marine distress EPIRB. Upon activation, the GlobalFIX™ V4’s robust internal GPS accurately fixes your exact location. Your coordinates are then broadcast via a powerful 406 MHz distress signal to Search and Rescue forces worldwide. In the absence of GPS data, orbiting Cospas-Sarsat satellites can accurately triangulate your position using the 406 MHz signal alone. A 121.5 MHz homing signal further guides searchers to your exact position.


Part Number

2830 (Category I)

Model Number

RLB-41

Size (no antenna)

8.13 (H) X 4.28” (W) (20.7 X 10.9 cm)

Weight

 66.10 oz (1874 g)

Weight (beacon only)

27 oz (764 g)

GPS

Internal GPS (66 Channel)

Battery

Class 2 (non-hazmat) lithium battery (user replaceable) - LiMnO2 (P/N 1104)

Battery Replacement

10 year user replaceable battery (replace 10 years after date of manufacture or after activation)

Material

High impact UV resistant polymer

Strobe

4 LED Array Strobe Light

Deployment

Category I - Hydrostatic release (auto)

Activation

Out of bracket and wet, or manually in or out of bracket

Waterproof

33 ft (10 m) for 5 min.

Output Power

5 W +/- 2dB (406.037 MHz); 50 mW +/-3dB (121.5 MHz)

Operational Life

48 hours minimum @ -4°F (-20°C)

Typical Performance

+48 hrs. @ -4°F (-20°C); Longer in higher ambient temperature

Operating Temp.

-4°F to +131°F (-20°C to +55°C ) (Class 2)

Storage Temp.

-22°F to + 158°F (-30°C to +70°C)

Accessories

SeaShelter™4 (P/N 2832), QuickDraw™ V4 (P/N 2833), Cat I HydroFix™ HRU (P/N 9490.1)

Approvals

Cospas-Sarsat, FCC, MED (Pending), IC Acceptances: USCG Meets: GMDSS, RTCM, IEC, and IMO standards

406Link.com

120 satellite detectable basic self tests (available only in the Americas)
